Descripción
Design
Three-way bass reflex
Drive units
Uni-Q Driver Array:
HF: 19 mm (0.75 in.) vented aluminium dome with MAT
MF: 100 mm (4 in.) aluminium cone
Bass Unit:
LF: 2 x 165 mm (6.5 in.) hybrid aluminium cone
HF: 19 mm (0.75 in.) vented aluminium dome with MAT
MF: 100 mm (4 in.) aluminium cone
Bass Unit:
LF: 2 x 165 mm (6.5 in.) hybrid aluminium cone
Frequency range (-6dB)
39 Hz – 20 kHz
Typical in-room bass response (-6dB)
28 Hz
Frequency response (±3dB)
46 Hz – 20 kHz
Crossover frequency
440 Hz, 2.3 kHz
Amplifier requirements
15 – 200 W
Sensitivity (2.83V/1m)
87 dB
Harmonic distortion (90dB, 1m)
<2% 35 Hz and above
<1% 38 Hz – 20 kHz
<1% 38 Hz – 20 kHz
Maximum output
110 dB
Impedance
4 Ω (min. 3.2 Ω)
Weight *
18.4 kg (40.6 lbs.)
Dimension (H x W x D) with terminal *
950 x 210 x 315 mm (37.4 x 8.3 x 12.4 in.)
Dimension (H x W x D) with terminal with Plinth *
1001 x 317 x 315 mm (39.4 x 12.5 x 12.4 in.)
Finishes
Satin Black / Satin White / Walnut
