Descripción
DESIGN
Three-way bass reflex
DRIVE UNITS
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass Unit:
LF: 2 x 130 mm (5.25 in.) hybrid aluminium cone
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass Unit:
LF: 2 x 130 mm (5.25 in.) hybrid aluminium cone
CROSSOVER FREQUENCY
400 Hz, 2.7 kHz
FREQUENCY RANGE (-6dB)
38 Hz – 50 kHz
TYPICAL IN-ROOM BASS RESPONSE (-6dB)
29 Hz
FREQUENCY RESPONSE (±3dB)
52 Hz – 28 kHz
HARMONIC DISTORTION (90dB, 1m)
<1% 75 Hz and above
<0.5% 110 Hz – 20 kHz
<0.5% 110 Hz – 20 kHz
MAXIMUM OUTPUT
110 dB
AMPLIFIER REQUIREMENTS
15 – 200W
NOMINAL IMPEDANCE
4 Ω (min. 3.2 Ω)
SENSITIVITY (2.83V/1m)
87 dB
WEIGHT *
24.5 kg (54.0 lbs)
DIMENSION (H x W x D) WITH TERMINAL *
1025 x 175 x 344 mm (40.4 x 6.9 x 13.5 in.)
DIMENSION (H x W x D) WITH TERMINAL WITH PLINTH *
1072 x 272 x 344 mm (42.2 x 10.7 x 13.5 in.)
FINISHES
Black Gloss / White Gloss / Walnut
