Descripción

• Amplificador estéreo

• 70 W por canal (8 ohmios)

• Procesamiento AL32

• DAC USB

• Controles eléctricos de alta precisión

• Entrada de fono MM/MC

• Unit (W x D x H)434 x 410 x 135mm
  17.1 x 16.1 x 5.3in
• Cabinet Size (W x D x H)434 x 374 x 135mm
  17.1 x 14.7 x 5.3in
• Net weight17.6kg
  38.8lb
• Packaging Dimensions (W x D x H)548 x 520 x 249mm
  21.6 x 20.5 x 9.8in
• Packaging gross weight20.4kg
  45lb
• Carton Color2 Color
• Cushion / Packing4 Separate / Sheet
• Panel ColorSP / BK
• Front (Center) PanelAluminum
• Side coverSECC with 4 straight emboss
• Side screwSP: Nickel / BK: Black
• Rear PanelSECC t1.0mm
• Chassis MaterialSECC t1.2mm
• Bottom LayerSingle
• Volume KnobAluminum
• Input SelectorAluminum
• Bass/Treble/Balance/ Phono Sel knobsAluminum
• Power buttonAluminum
• Other knob/button (LOUDNESS, SOURCE DIRECT etc)Mold (Source Direct,Analog Mode,MM/MC)
• FootABS resin with rigid rib
  w/Hot stamp
  (H : 20mm)
• Heatsink for Power AmplifierExtruded Aluminum
• Rated Output Power70W + 70W
  (8ohm,20Hz-20kHz,THD0.07%)
  140W + 140W
  (4ohm, 1kHz, THD0.7%)
• Speaker ImpedanceA or B : 4 ~ 16ohm
  A + B : 8 ~ 16ohm
• Frequency Response5Hz – 100kHz (0~ -3dB)
• Total Harmonic Distortion0.01 % (Rated output: –3 dB),
  8 ohm/ohms, 1 kHz
• Input Sensitivity: Phono inputMM: 2.5 mV / 47 kohm
  MC: 200
• RIAA Deviation20 Hz – 20 kHz ±0.5 dB (MM/MC)
• Phono Maximum InputMM : 130mV / 1kHz
  MC : 10mV / 1kHz
• Input Sensitivity: CD/LINE/RECORDER125 mV / 19 kohm
• Input Sensitivity: Power Amp input0.85V / 47kohm (EXT. PRE)
• Signal to Noise RatioPHONO (MM): (89dB)
  PHONO (MC): (74dB)
  CD: (107dB)
• Tone ControlBASS : 100Hz ±8dB
  TREBLE : 10kHz ±8dB
• Power Consumption295W
• at Standby0.2W TV autoplay off
  0.4W TV autoplay on
